Traditional Chinese Medicine Pieces Belt Dryer

Introduction: The drying method of traditional Chinese medicine decoction pieces is directly related to the quality of the decoction pieces. In the past, drying with solar houses not only met the certification requirements but also reduced costs. However, the desig…

Hotline: 0086-15380092122
Inquiry
Case Details Photo Gallery

  The drying method of traditional Chinese medicine decoction pieces is directly related to the quality of the decoction pieces. In the past, drying with solar houses not only met the certification requirements but also reduced costs. However, the design of solar houses of a few companies is not reasonable. One is that the area is small and cannot meet the production requirements. The second is that the facilities of the solar house are not perfect, with only dustproof function, without supporting ventilation, dehumidification, floor racks and other devices, and the drying speed is slow. According to the characteristics of Chinese herbal medicine decoction pieces, the company designs a belt dryer that meets the characteristics of traditional Chinese medicine decoction pieces. The belt dryer equipment is used to dry the decoction pieces, which is not affected by the climate, is dry and hygienic than natural, and can shorten the drying time, and can also be mass-produced .

Equipment Overview of Belt Dryer for Chinese Herbal Medicine Pieces

  Traditional Chinese medicine decoction piece belt dryer is composed of feed system, cloth system, inlet filter system, heating and cooling system, host, transmission system, bypass filter system, discharge system, exhaust air and moisture removal system, control system, etc. When working, the material is fed from the feeding system to the cloth system, and the material is added to the belt dryer. The material meets the through-flow hot air and cold air passing through the mesh belt, and conducts heat and mass transfer. The hot air is recycled to make energy consumption more After reaching a certain humidity, some forced dehumidification will take away the moisture, and the material will be dried and cooled.

Equipment characteristics of traditional Chinese medicine decoction piece belt dryer

1. The inlet air temperature of hot air is displayed and controlled by the ratio regulating valve, so as to control the inlet air temperature within the set range.
2. The speed of the mesh belt is adjustable by frequency conversion, which ensures the residence time of the material and also ensures the quality of the discharge.
3. The drive motor, mixing motor, and moisture exhaust fan are adjustable in frequency.
4. The bottom of the mesh belt at the bottom of the belt machine is made an inclined surface for material collection and cleaning.
5. After the equipment is manufactured, the transmission and conveying system is in trial operation, and there is no abnormal noise and jamming.
6. An ultrasonic material level detector is installed on the mixing silo to ensure a reasonable material level, and it is linked with the front conveyor line to make the production line more smooth.
7. The doors of each part on the box body are well insulated, sealed, and easy to open and close.
8. There are cleaning and maintenance doors on both sides of each unit, which can directly flush the inside of the equipment.



Applicable materials for belt dryer of traditional Chinese medicine decoction pieces

According to the temperature and speed of the equipment parameters, the Chinese herbal medicine dryer can dry most Chinese herbal medicines, and almost all Chinese herbal medicines such as flakes and powders can be dried.


Photo Gallery
  • Traditional Chinese Medicine Pieces Belt Dryer
  • Traditional Chinese Medicine Pieces Belt Dryer
